3 Faz AC Load Bank

RLC 3 faz AC chaj bank, refere yo kòm chaj RLC pou kout, ke yo rele tou RLC AC chaj, se sitou itilize nan jaden yo nan deteksyon varyateur, deteksyon ekipman pou pouvwa UPS, deteksyon mete dèlko, elatriye 3 faz bank chaj la gen ladan. twa-faz R, RL, RC, RLC, RCD ak lòt bank chaj ekipman pou pouvwa AC, ki ka refwadi pa dlo oswa lè.

Voye rechèch

PWODIKSYON PWODIKSYON Jeneral

FOTO PWODWI

SENARIO APLIKASYON

PARAMÈT PASYÈL

Remak: tout paramèt yo se pou referans sèlman epi yo ka Customized
Non pwodwi	3 faz AC chaj bank
Espesifikasyon	Bank chaj RLC
Fòmasyon	Yon bank chaj (ki gen ladan chaj rezistans sèk, konpozan kontwòl elektrik, mezi ak sistèm kontwòl)
Chaje etap	Dapre bezwen kliyan yo
Koneksyon chaj	Ba kòb kwiv mete
Rezistans	Each resistance element: insulation impedance DC1000V/100MΩ above Kenbe vòltaj AC 2000v pou 5min Resistance error of each resistance tube:±3 percent
Kontwòl chaj	Kontwòl manyèl lokal, kontwòl otomatik lokal oswa kontwòl otomatik aleka ka chwazi
Chaje presizyon	Mwens pase oswa egal a 3 pousan
Balans twa faz	Dezekilib degre mwens pase oswa egal a 3 pousan
Etap minimòm	1kW
Mòd travay	Travay kontinyèl
Pwoteksyon chaj	Kout kous, surkouran, tanperati ki wo, pwoteksyon fay fanatik
Ekstèn pouvwa	TN-C,380V/50Hz
Mòd refwadisman	Fòse refwadisman lè, priz lè bò oswa priz lè tèt
Klas izolasyon	F
Presizyon mezi	Presizyon ekspozisyon an se {{0}}.5, presizyon echantiyon an se 0.2
Ekspozisyon paramèt elektrik	Twa faz vòltaj, twa-faz aktyèl, frekans, pouvwa, elatriye
Mòd vòltaj k ap monte	Reyalize pa transfòmatè
Ekspansyon chaj	Ekspansyon paralèl nan resipyan chaj miltip
Estanda	Satisfè estanda entènasyonal, estanda bato, estanda militè ak estanda telekominikasyon
Transpò	Bank chaj la gen yon twou pou leve-chaj, ki satisfè kondisyon transpò long-
Koulè	Customized
Tanperati anbyen	-20 degre a 50 degre
Imidite	Jiska 100 pousan
Altitid	Jiska 2500m
Presyon atmosferik	86 rive 106kPa

PLIS SPECIFICATIONS

Remak: tout paramèt yo se pou referans sèlman epi yo ka Customized
Pouvwa (kW)	Voltaj (kV)	Frekans (Hz)	Gwosè (mm, LWH)	Pwa (Kg)
Ba vòltaj
100	0.4	50	11009001000	320
200	0.4	50	135011001100	450
300	0.4	50	150012001200	650
400	0.4	50	170015001500	830
500	0.4	50	170016001600	950
600	0.4	50	180016001600	1150
800	0.4	50	190018001700	1900
1000	0.4	50	230017002100	2100
1200	0.4	50	250018002200	2300
1500	0.4	50	250018602300	2600
1800	0.4	50	300020002300	4000
2000	0.4	50	300020002300	5000
2500	0.4	50	400024382500	6000
3000	0.4	50	600024382500	7000
Mwayen vòltaj
1000	6/10.5	50/60	300024382500	3500
1200	6/10.5	50/60	400024382500	3900
1500	6/10.5	50/60	400024382500	4500
1600	6/10.5	50/60	500024382500	5000
1800	6/10.5	50/60	500024382500	6500
2000	6/10.5	50/60	600024382500	7500
2200	6/10.5	50/60	600024382500	8000
2500	6/10.5	50/60	600024382500	10000
3000	6/10.5	50/60	700024382500	12000
4000	6/10.5	50/60	800024382500	14000
5000	6/10.5	50/60	900024382500	15000
6000	6/10.5	50/60	1200024382500	16000
7000	6/10.5	50/60	1200024382500	17000
8000	6/10.5	50/60	1200024382500	18000

DESEN DESIGN

Anbalaj ak anbake

①Before leaving the factory, check all parts of the product to check whether the product can be used and installed normally.

②When packing the load bank, special parts such as cables and important parts of the load box shall be separately packed and specially packed.

③The export shipping mode of container shall be adopted. Due to its own characteristics, the front and rear dimensions and left and right dimensions of large container bank load exceed the entrance width of ordinary containers, so it can not be directly loaded into common containers. Therefore, we use bulk cargo shipping or customized frame containers with higher prices. You can also make the best packaging and transportation plan according to your needs.

④If you need OEM and ODM services and have separate bank packaging schemes and logo printing standards, please connect your schemes and standards with us in advance. We can pack the products according to your requirements.

⑤Because the load bank is a large heavy object, we usually choose sea transportation, land transportation and railway transportation.

⑥Small load banks can design handles and rollers, medium load banks can design lifting holes, forklift holes or rollers, and large load banks can design lifting holes and rollers. Easy to move and transport.

KALIFIKASYON ONORE

Depi kreyasyon li, Rata te jwenn 16 sètifika patant modèl sèvis piblik ak 8 sètifika anrejistreman dwadotè lojisyèl òdinatè, epi li te rekonèt kòm yon antrepriz nasyonal wo-teknoloji.
